3D Microelectronic Packaging From Architectures to Applications

15% sparen

166,99 € UVP 197,99 €

inkl. gesetzl. MwSt., Versandkostenfrei


Beschreibung

Produktdetails

Einband

Gebundene Ausgabe

Erscheinungsdatum

24.11.2020

Herausgeber

Yan Li + weitere

Verlag

Springer Singapore

Seitenzahl

622

Maße (L/B/H)

24,1/16/4 cm

Gewicht

1115 g

Auflage

Second Edition 2021

Sprache

Englisch

ISBN

978-981-15-7089-6

Beschreibung

Portrait

Dr. Yan Li is currently a senior staff package engineer in Assembly Test and Technology Development Failure Analysis Lab of Intel Corporation located in Chandler, Arizona. Dr. Li received her Ph.D. degree in Materials Science and Engineering from Northwestern University in 2006, and her M.S and B.S degree in Physics from Peking University. As the lead package failure analysis engineer of 3D package technology development projects in Intel, Dr. Li has been actively involved in numerous packaging related technical solutions, and focusing on the quality and reliability of electronic packages, fundamental understanding of failure modes and failure mechanisms of electronic packages, developing new tools and techniques for fault isolation and failure analysis of 3D electronic packages. Dr. Li is a senior member and contributor of many international professional associations, such as Minerals Metals and Materials Society (TMS), American Society for Metals (ASM), and Electronic Device Failure Analysis Society (EDFAS). She has been appointed as TMS and International Symposium for Testing and Failure Analysis (ISTFA) annual conference organizer since 2011. Dr. Li joined the technical committee of International Symposium on the Physical and Failure Analysis of Integrated Circuits. (IPFA) since 2018. She was granted the TMS EMPMD Young Leader Professional Development Award in 2014. Dr. Li has published over 20 papers and two patents in the microelectronic packaging area. She is the co-editor of a semiconductor industry highly recognized book: “3D Microelectronic Packaging: From Fundamentals to Applications” by Springer.

Dr. Deepak Goyal is currently the Director of the ATTD/ATM Package FA & LYA Labs at Intel. Dr. Goyal graduated with a PhD in Materials Science and Engineering from State University of New York, Stony Brook. His responsibilities include development of the next generation of analytical tools and techniques, defect characterization, fault isolation, failure and materials analyses for the next generation package, substrates and boards technology development at Intel and Package FA/LYA for Intel’s Assembly Test and Manufacturing. He has helped with the development of all Intel assembly technologies including FCxGA, FCCSP, TSVs, EMIB and Foveros. He is an expert in the failure analysis of packages and has taught Professional Development courses on Package FA/FI methods and failure mechanisms at the Electronics Components and Technology Conference (ECTC). He has won two Intel Achievement Awards and 25 Division Recognition Awards at Intel. Deepak has authored and co-authored over 50 papers and holds 11 US patents with 5 more in flight. He has co-authored several book chapters and has co-edited a book titled “3D Microelectronic Packaging - From Fundamentals to Applications”. He is a senior member of the IEEE and was the chair of the Package and Interconnect Failure Analysis Forum sponsored by the International Sematech and a past chair of theECTC Applied Reliability Committee.



Produktdetails

Einband

Gebundene Ausgabe

Erscheinungsdatum

24.11.2020

Herausgeber

Verlag

Springer Singapore

Seitenzahl

622

Maße (L/B/H)

24,1/16/4 cm

Gewicht

1115 g

Auflage

Second Edition 2021

Sprache

Englisch

ISBN

978-981-15-7089-6

Herstelleradresse

Springer-Verlag KG
Sachsenplatz 4-6
1201 Wien
AT

Email: GPSR Kontakt

Noch keine Bewertungen vorhanden

Verfassen Sie die erste Bewertung zu diesem Artikel

Helfen Sie anderen Kundinnen und Kunden durch Ihre Meinung.

Kundinnen und Kunden meinen

Bewertungen (0)

  • Produktbild: 3D Microelectronic Packaging
  • Produktbild: 3D Microelectronic Packaging
  • 1. Introduction to 3D microelectronic packaging.- 2. 3D packaging architecture and assembly process design.- 3. Fundamentals of TSV processing and reliability.- 4. Mechanical properties of TSV.- 5. Atomistic View of TSV Protrusion/Intrusion.- 6. Fundamentals and failures in Die preparation for 3D packaging.- 7. Direct Cu to Cu bonding and other alternative interconnects in 3D packaging.- 8. Emerging hybrid bonding techniques for 3D packaging.- 9. Fundamental of Thermal Compressive Bonding process, advanced epoxy, and flux materials in 3D packaging.- 10. Fundamentals of solder alloys in 3D packaging.- 11. Fundamentals of electro migration in interconnects of 3D packages.- 12. Fundamentals of heat dissipation in 3D packaging.- 13. Fundamentals of advanced materials and process in substrate technology.- 14. New substrate technologies for 3D packaging. -15. Thermal mechanical and moisture modeling in 3D packaging.- 16. Stress and Strain measurements in 3D packaging.- 17.Processing and Reliability of Solder Interconnections in Stacked Packaging.- 18. Interconnect Quality and Reliability of 3D Packaging.- 19. Fundamentals of automotive reliability of 3D packages.- 20. Fault isolation and failure analysis of 3D packaging.
